Gilson Elutriation Sieves offer a labor-saving, repeatable alternative to conventional wet-wash sieves for manual wet-washing of soil, aggregate, ore or other samples. They use gentle air and water agitation for fines removal from specimens through a single mesh size of stainless steel wire cloth.
A cone-shaped well is machined into the solid base and an injection tube directs air and water into the bottom of the well. Sieves have a sturdy, thick-walled acrylic cylinder with four vertical openings, covered by ASTM E 11 Testing Grade stainless steel wire cloth. The total sieving area is about 12% greater than a standard 8in diameter sieve. Port opening of the sieve body is 7x2in (178x51mm).
Compressed air and running water supplies are required. Other mesh sizes of stainless steel wire cloth and nylon or polyester cloth can be quoted on request.
Features:
- Repeatable alternative for fines removal of soil, aggregate, ore or other samples
- Reduced labor compared to manual wet-washing
Included Items:
- Elutriation Sieve with wire cloth
- Injection tube
Material Acrylic
Opening Size 7x2in (178x51mm) WxH
Product Dimensions 3.25 x 15in (83 x 380mm), Dia.xH
Meets Test Methods:
AASHTO M 92
ASTM E 11
The Gilson SVA-25 Elutriation Sieve, No. 325, is a high-quality product designed to offer a labor-saving and repeatable alternative to conventional wet-wash sieves. This innovative sieve is perfect for manual wet-washing of soil, aggregate, ore, and other samples, providing efficient fines removal in a simple and effective manner.
The Gilson Elutriation Sieve utilizes gentle air and water agitation to remove fines from specimens through a single mesh size of stainless steel wire cloth. The solid base of the sieve features a cone-shaped well, while an injection tube directs air and water into the bottom of the well. With its sturdy and thick-walled acrylic cylinder, the sieve ensures durability and longevity.
One of the notable features of the Gilson Elutriation Sieve is its larger sieving area, offering approximately 12% more space than a standard 8-inch diameter sieve. The sieve body has four vertical openings covered by ASTM E 11 Testing Grade stainless steel wire cloth, providing an effective filtration process for your samples.
Measuring 7x2 inches (178x51mm) in size, the sieve is designed for convenience and practicality. It requires compressed air and a running water supply to function optimally. However, if you require a different mesh size or fabric material such as nylon or polyester cloth, our team can provide you with a custom quote upon request.
With the Gilson SVA-25 Elutriation Sieve, you can enjoy the benefits of reduced labor compared to traditional manual wet-washing methods. It streamlines the fines removal process, ensuring accurate and consistent results with every use.
Included with the sieve are the elutriation sieve itself, complete with wire cloth, as well as an injection tube for efficient air and water distribution.
Constructed from high-quality acrylic, this product is built to last, offering reliability and durability. With dimensions of 3.25 x 15 inches (83 x 380 mm), it is compact enough to fit into any laboratory setting.
The Gilson SVA-25 Elutriation Sieve meets various test methods, including AASHTO M 92 and ASTM E 11, ensuring industry-standard compliance and reliable performance.
Choose the Gilson SVA-25 Elutriation Sieve for your fines removal needs and experience a labor-saving and repeatable alternative that delivers consistent and accurate results every time.
