HiTemp 140 Temperature Data Logger with 2in Flex Probe, NIST

The HiTemp 140 is a durable, high-precision temperature data logger designed for extreme environments such as autoclaves, sterilizers, ovens, research labs, and food processing facilities.

Built with stainless steel and fully submersible, it can withstand temperatures up to 140°C (284°F) with an impressive accuracy of +/-0.1°C (0.18°F) across its entire range. With a storage capacity of up to 32,700 date- and time-stamped readings, its non-volatile memory ensures data is retained even if the battery runs out.

Pair the HiTemp 140 with the USB Docking Station and Software (sold separately) for easy setup, data download, and management. Analyze results in graphical, tabular, or summary formats with options to view data in °C, °F, K, or °R. For deeper analysis, data can be automatically exported to Excel®.

FEATURES:

• ±0.1°C (0.18°F) Accuracy
• Operates Up To 140°C (284°F)
• Submersible (IP68)
• Rugged Stainless Steel Housing
• User Replaceable Battery
• Rugged
• Programmable start time
• Programmable stop time
• Engraved Label
• Probe Lengths Up To 7”
• Battery Life Indicator
• NIST Traceable Certificate, not included, but available

SPECIFICATIONS:

Temperature Sensor:  100Ω Platinum RTD

Operating Environment Range (submerged): -40 to +140ºC (-40 to +284ºF), 0%RH to 100%RH

Probe Temperature Range:     -200 to +260°C (-328 to +500°F)

Temperature Resolution:        0.01ºC (0.02ºF)

Calibrated Accuracy:   ±0.1°C / ±0.18°F (20 to +140°C / 68 to +284°F)

Start Modes:   “Software programmable immediate start Delay start up to eighteen months in advance”

Stop Modes:   “Manual through software Timed (specific date and time)”

Real Time Recording:  May be used with PC to monitor and record data in real time

Password Protection:  An optional password may be programmed into the device to restrict access to configuration options. Data may be read out without the password.

Memory:         32,700 readings

Wrap Around: Yes

Reading Rate:  One second up to once every 24 hours

Battery Type:   3.6v high-temperature lithium battery included; user replaceable

Battery Life:     1 year typical (1 minute reading rate at 25ºC/77ºF)

Calibration:     Digital calibration through software

Calibration Date:         Automatically recorded within device

Data Format:   Date and time stamped ºC, ºF, K, ºR

Time Accuracy:           ±1 minute/month at 20ºC to 30ºC (68ºF to 86ºF) (Stand alone mode)

Computer Interface:   IFC 400 USB docking station required 125,000 baud

Dimensions (Body):    2.7” x 0.97” dia. (67mm x 25mm dia.)

Dimensions (Probe**):           2” x .188” to .125” transitional dia. 50mm x 3.8mm to 3.2mm transitional dia.

Weight:           4.2 oz (120g)

Material:         316 Stainless Steel
